Level radar solid

For simple applications:
Reliable, non-contact measurement of levels
in silos or storage tanks for bulk solids

Heartbeat Verification + Monitoring, Bluetooth® Commissioning,
operation and maintenance with SmartBlue App,
HistoROM, RFID TAG for easy identification

2-wire (HART/ PROFIBUS PA)
PROFINET with Ethernet-APL
Bluetooth® wireless technology

W-Band (~80 GHz)

1-1/2″ / 40mm encapsulated, PVDF
2″ / 50mm Drip-off, PTFE

+/- 3 mm (0.12 in)

-40 … +85 °C (-40 … +185 °F)

-40 … +130 °C (-40 … +266 °F)

Vacuum…16 bar (232 psi)

PVDF or PTFE

Thread:
G1-1/2″, MNPT1-1/2″
Flange:
UNI DN80…DN150
Mounting bracket

50 m (164 ft)

HART/ PROFIBUS PA
PROFINET with Ethernet-APL
Bluetooth® wireless
technology and app (optional)

IEC Ex, ATEX, CSA C/US, EAC Ex, JPN Ex,
KC Ex, INMETRO Ex, NEPSI Ex, UK Ex

SIL

EU Food Contact Material (EC) 1935/2004;
US Food Contact Material FDA CFR 21;
Declaration of Conformity ASME B31.3;
CRN approval

KR, ABS, LR, BV, RINA, DNV GL

Display, Customized settings,
App ‘SmartBlue’ for commissioning and operation via Bluetooth
Heartbeat for batch detection; Gas-tight implementation;
Overvoltage protection; PWIS free

DK < 1.6
Reduction of the max. possible measuring range due to:
Media with poor reflective properties cone of repose
extremely loose surface of bulk solids, e.g. bulk solids with a
low bulk density during pneumatic filling buildup, especially of
moist products.
Alternative for these applications: FMR67B
