Level radar

Premium device for continuous non-contact level measurement
with hygienic requirements (ASME BPE, USP Class VI);

Heartbeat Technology,
SIL 2/3 according to IEC 61508,
Bluetooth® commissioning;
Operation and maintenance with SmartBlue app;
HistoROM;
RFID TAG for easy identification;
Very narrow beam angle

2-wire (HART/ PROFIBUS PA)
PROFINET with Ethernet-APL
Bluetooth® wireless technology

W-Band (~80 GHz)

+/-1 mm (0.04 in)

-40 °C … +85 °C (-40 °F … +185 °F)

-40 °C … +200 °C (-40 °F … +392 °F)

Vacuum…25 bar (363 psi)

PEEK or PTFE

Thread:
M24

NEUMO BioControl;
Slotted-nut DIN11851;
Varivent;
Tri-Clamp ISO2852

80 m (262 ft)

HART/ PROFIBUS PA
PROFINET with Ethernet-APL
Bluetooth® wireless
technology and app (optional)

IEC Ex, ATEX, CSA C/US, EAC Ex, JPN Ex, KC Ex,
INMETRO Ex, NEPSI Ex, UK Ex;

Overfill protection WHG;
KTW drinking water approval W270;
NSF/ANSI 61 drinking water approval;
SIL 2/ SIL 3

Acceptance test certificate 3.1, EN10204;
EU Food Contact Material (EC) 1935/2004;
US Food Contact Material FDA CFR 21;
Declaration of Conformity ASME B31.3;
Conformity to cGMP;
CoC ASME BPE;
CRN approval

3-A;
EHEDG;
CoC-ASME BPE

Display,
Customized settings,
App ‘SmartBlue’ for commissioning and operation via Bluetooth
Gas-tight implementation;
Overvoltage protection;
PWIS free

Process temp. > 200°C (392°F) -> FMR62
Strong foam, stilling well and bypass (>10 m) -> FMR5x,FMP5x
